Florencite-(Sm)

This page is currently not sponsored. Click here to sponsor this page.
Hide all sections | Show all sections

About Florencite-(Sm)Hide

Formula:
SmAl3(PO4)2(OH)6
Colour:
Colourless
Lustre:
Greasy
Hardness:
5½ - 6
Specific Gravity:
3.70
Crystal System:
Trigonal
Name:
Sm-dominant member of the florencite group. The florencite root name is for Dr. William Florence (1864-1942), Brazilian mineralogist who made a preliminary chemical examination of what is now called florencite-(Ce).
Sm-analogue of Florencite-(Ce) and waylandite. Unique combination of elements. Second samarium-dominant mineral after monazite-(Sm).


Classification of Florencite-(Sm)Hide

Approved
Approval Year:
2009
8.BL.13

8 : PHOSPHATES, ARSENATES, VANADATES
B : Phosphates, etc., with additional anions, without H2O
L : With medium-sized and large cations, (OH, etc.):RO4 = 3:1

Physical Properties of Florencite-(Sm)Hide

Greasy
Transparency:
Transparent
Colour:
Colourless
Comment:
Pale pink to pale yellow in aggregates
Streak:
White
Hardness:
5½ - 6 on Mohs scale
Tenacity:
Brittle
Cleavage:
Distinct/Good
on {0001}
Parting:
Observed parallel to {1120}
Fracture:
Irregular/Uneven
Density:
3.70(1) g/cm3 (Measured)    3.743 g/cm3 (Calculated)

Optical Data of Florencite-(Sm)Hide

Type:
Uniaxial (+)
RI values:
nω = 1.704() nε = 1.713(2)
Max Birefringence:
δ = 0.009
Image shows birefringence interference colour range (at 30µm thickness)
and does not take into account mineral colouration.
Surface Relief:
High
Pleochroism:
Non-pleochroic

Chemical Properties of Florencite-(Sm)Hide

Formula:
SmAl3(PO4)2(OH)6

Crystallography of Florencite-(Sm)Hide

Crystal System:
Trigonal
Class (H-M):
3m (3 2/m) - Hexagonal Scalenohedral
Space Group:
R3m
Cell Parameters:
a = 6.972(4) Å, c = 16.182(7) Å
Ratio:
a:c = 1 : 2.321
Unit Cell V:
681.2 ų
Z:
3
Morphology:
In the inner part of acute rhombohedral florencite-(Ce) crystals.

X-Ray Powder DiffractionHide

Powder Diffraction Data:
d-spacingIntensity
5.65 (43)
3.479 (37)
2.925 (100)
2.191 (22)
2.161 (46)
1.881 (58)
1.738 (20)

Type Occurrence of Florencite-(Sm)Hide

Synonyms of Florencite-(Sm)Hide

Relationship of Florencite-(Sm) to other SpeciesHide

Other Members of this group:
BenauiteSrFe3+3(HPO4,PO4)2(OH)6Trig. 3m (3 2/m) : R3m
CrandalliteCaAl3(PO4)(PO3OH)(OH)6Trig. 3m (3 2/m) : R3m
EylettersiteTh0.75Al3(PO4)2(OH)6Trig.
Florencite-(Ce)CeAl3(PO4)2(OH)6
Florencite-(La)LaAl3(PO4)2(OH)6
Florencite-(Nd)NdAl3(PO4)2(OH)6
GalloplumbogummitePb(Ga,Al,Ge)3(PO4)2(OH)6Trig. 3m : R3m
GorceixiteBaAl3(PO4)(PO3OH)(OH)6Mon. m : Bm
GoyaziteSrAl3(PO4)(PO3OH)(OH)6Trig. 3m (3 2/m) : R3m
KintoreitePbFe3(PO4)(PO3OH)(OH)6Trig. 3m (3 2/m) : R3m
Kintoreite-2cPbFe3+3(PO4)2(OH,H2O)6
PlumbogummitePbAl3(PO4)(PO3OH)(OH)6Trig. 3m (3 2/m) : R3m
SpringcreekiteBaV3+3(PO4)2(OH,H2O)6Trig. 3m (3 2/m) : R3m
Unnamed (As-analogue of Zaïrite)(Bi,Pb)Fe3+3(AsO4)2(OH)6
WaylanditeBiAl3(PO4)2(OH)6Trig. 3m (3 2/m) : R3m
ZaïriteBiFe3+3(PO4)2(OH)6Trig. 3m (3 2/m) : R3m

Common AssociatesHide

Associated Minerals Based on Photo Data:
Florencite-(Ce)3 photos of Florencite-(Sm) associated with Florencite-(Ce) on mindat.org.
Florencite-(Nd)3 photos of Florencite-(Sm) associated with Florencite-(Nd) on mindat.org.
Quartz3 photos of Florencite-(Sm) associated with Quartz on mindat.org.

Related Minerals - Nickel-Strunz GroupingHide

8.BL.05BeudantitePbFe3(AsO4)(SO4)(OH)6Trig. 3m (3 2/m) : R3m
8.BL.05CorkitePbFe3(PO4)(SO4)(OH)6Trig. 3m (3 2/m) : R3m
8.BL.05HidalgoitePbAl3(AsO4)(SO4)(OH)6Trig.
8.BL.05HinsdalitePbAl3(PO4)(SO4)(OH)6Trig. 3m (3 2/m) : R3m
8.BL.05KemmlitziteSrAl3(AsO4)(SO4)(OH)6Trig.
8.BL.05SvanbergiteSrAl3(PO4)(SO4)(OH)6Trig. 3m (3 2/m) : R3m
8.BL.05WoodhouseiteCaAl3(PO4)(SO4)(OH)6Trig. 3m (3 2/m) : R3m
8.BL.05GallobeudantitePbGa3(AsO4)(SO4)(OH)6Trig.
8.BL.10ArsenogoyaziteSrAl3(AsO4)(AsO3OH)(OH)6Trig. 3m (3 2/m) : R3m
8.BL.10ArsenogorceixiteBaAl3(AsO4)(AsO3OH)(OH)6Trig. 3m (3 2/m) : R3m
8.BL.10ArsenocrandalliteCaAl3(AsO4)(AsO3OH)(OH)6Trig. 3m (3 2/m)
8.BL.10BenauiteSrFe3+3(HPO4,PO4)2(OH)6Trig. 3m (3 2/m) : R3m
8.BL.10CrandalliteCaAl3(PO4)(PO3OH)(OH)6Trig. 3m (3 2/m) : R3m
8.BL.10DussertiteBaFe3+3(AsO4)(AsO3OH)(OH)6Trig. 3m (3 2/m) : R3m
8.BL.10EylettersiteTh0.75Al3(PO4)2(OH)6Trig.
8.BL.10GorceixiteBaAl3(PO4)(PO3OH)(OH)6Mon. m : Bm
8.BL.10GoyaziteSrAl3(PO4)(PO3OH)(OH)6Trig. 3m (3 2/m) : R3m
8.BL.10KintoreitePbFe3(PO4)(PO3OH)(OH)6Trig. 3m (3 2/m) : R3m
8.BL.10PhilipsbornitePbAl3(AsO4)(AsO3OH)(OH)6Trig.
8.BL.10PlumbogummitePbAl3(PO4)(PO3OH)(OH)6Trig. 3m (3 2/m) : R3m
8.BL.10SegnititePbFe3+3AsO4(AsO3OH)(OH)6Trig. 3m (3 2/m) : R3m
8.BL.10SpringcreekiteBaV3+3(PO4)2(OH,H2O)6Trig. 3m (3 2/m) : R3m
8.BL.13Arsenoflorencite-(La)LaAl3(AsO4)2(OH)6Trig. 3m (3 2/m) : R3m
8.BL.13Arsenoflorencite-(Nd)NdAl3(AsO4)2(OH)6Trig.
8.BL.13Arsenoflorencite-(Ce)CeAl3(AsO4)2(OH)6Trig. 3m (3 2/m) : R3m
8.BL.13Florencite-(Ce)CeAl3(PO4)2(OH)6
8.BL.13Florencite-(La)LaAl3(PO4)2(OH)6
8.BL.13Florencite-(Nd)NdAl3(PO4)2(OH)6
8.BL.13WaylanditeBiAl3(PO4)2(OH)6Trig. 3m (3 2/m) : R3m
8.BL.13ZaïriteBiFe3+3(PO4)2(OH)6Trig. 3m (3 2/m) : R3m
8.BL.13ArsenowaylanditeBiAl3(AsO4)2(OH)6Trig.
8.BL.13Graulichite-(Ce)CeFe3+3(AsO4)2(OH)6Trig. 3m (3 2/m) : R3m
8.BL.15ViitaniemiiteNa(Ca,Mn2+)Al(PO4)(F,OH)3Mon.
8.BL.25PattersonitePbFe3+3(PO4)2(OH)5 · H2OTric. 1 : P1

Other InformationHide

Health Risks:
No information on health risks for this material has been entered into the database. You should always treat mineral specimens with care.

References for Florencite-(Sm)Hide

Reference List:
Sort by Year (asc) | by Year (desc) | by Author (A-Z) | by Author (Z-A)
Repina, S.A., Popova, V.I., Churin, E.I., Belogub, E.V. and Chiller, V.V. (2010): Florencite-(Sm), (Sm,Nd)Al3(PO4)2(OH)6 - a new mineral of alunite-jarosite group from the Subpolar Urals. Zapiski Rossiyskogo Mineralogicheskogo Obshchestva, 139(4), 16-25 (in Russian). [English translation: (2011) Geology of Ore Deposits, 53, 564-574.]

Internet Links for Florencite-(Sm)Hide

Localities for Florencite-(Sm)Hide

This map shows a selection of localities that have latitude and longitude coordinates recorded. Click on the symbol to view information about a locality. The symbol next to localities in the list can be used to jump to that position on the map.

Locality ListHide

- This locality has map coordinates listed. - This locality has estimated coordinates. ⓘ - Click for further information on this occurrence. ? - Indicates mineral may be doubtful at this locality. - Good crystals or important locality for species. - World class for species or very significant. (TL) - Type Locality for a valid mineral species. (FRL) - First Recorded Locality for everything else (eg varieties). Struck out - Mineral was erroneously reported from this locality. Faded * - Never found at this locality but inferred to have existed at some point in the past (eg from pseudomorphs.)

All localities listed without proper references should be considered as questionable.
Russia (TL)

  • Northern Region
    • Komi Republic
      • Prepolar Ural
        • Kozhim River Basin
          • Maldynyrd range (Maldy-nyrd range)
            • Grubependity Lake
Repina, S.A., Popova, V.I., Churin, E.I., Belogub, E.V. and Chiller, V.V. (2010): Florencite-(Sm), (Sm,Nd)Al3(PO4)2(OH)6 - a new mineral of alunite-jarosite group from the Subpolar Urals. Zapiski Rossiyskogo Mineralogicheskogo Obshchestva, 139(4), 16-25 (in Russian). [English translation: (2011) Geology of Ore Deposits, 53, 564-574.]
